Groundcheck

A new circular woven geotextile manufactured using very strong 100% polypropylene tapes and distinguished by bright orange warp tapes . The product is CE marked making it suitable to go under not just a Whacker Plate but also under a Vibrating Sit-on Road Roller. Like all woven geotextiles this product is not recommended for applications such as Land Drainage and Weed Control. For Land Drainage we recommend Stratacheck and for Weed Control, Weedcheck Ultra.

Benefits
Suitable Applications
Installation Instructions

Prevents expensive aggregates from being lost into the sub soil
Suitable for pedestrian & Vehicle applications
Contributes at low maintenance gardening
Air & Liquid permeable
Extra Strong Tapes

Aggregate areas / scree areas
Garden paths
Horse manège and root protection
Under cellular confinement systems
Under Type 1 for stability for: block paved drives, artificial grass, and roads

1. Excavate to the appropriate depth for your application, compact the sub soil / substrate.

2. Lay the Groundcheck overlapping 250mm at joins and secure with polyprop barbed pegs.

3. Carefully cover with Type 1 or similar working from the Type 1 and not on the Groundcheck.

4. Level and compact using a vibrating plate or roller.

5. Groundcheck, because of the hole sizes, cannot be recommended for weed control but will suppress some weeds although rhizomes, bulbs and corns may penetrate.

Description	Roll sizes	Weight
Groundcheck	1m x15m, 1m x 25m, 1m x 50m, 1m x 100m, 1.5m x 15m, 2m x 10m, 2m x 25m, 2m x 50m, 2m x 100m, 3m x 100m, 4m x 12.5m, 4m x 100m (folded)	80gsm
