Rhinoplast Evolution H-D

Rhinoplast EvolutionHD is a high specification co-extruded multi-layer barrier engineered to provide exceptional protection on construction sites contaminated by volatile organic compounds, hydrocarbons, and ground gases such as methane, radon, and CO2. Additionally, this high-performance membrane doubles as a damp proof membrane.

Category:
Description Roll width Length Thickness M2/roll
Rhinoplast Evolution HD
1.65m
30.5m
0.6mm
50

• Designed to Integrate with the subsequently placed fresh concrete to give strong mechanical bond effect without adhesive, primers, heat or open flames

• Applied prior to fixing steel reinforcement

• Applied in a vertical and/or horizontal to blindside or under slab applications

• Used to create an integral seal between the concrete and the waterproofing membrane

• Specifically developed for use on construction sites contaminated by Volatile Organic Compounds, Hydrocarbons, and other ground gasses such as Methane, Radon and CO²

  • Virgin Grade Polymers: Ensures reliability and consistency in material performance.
  • Advanced Fourteen Layer Barrier: For ultimate protection and durability.
  • Dual EVOH Layers: Enhanced gas barrier effectiveness.
  • Encased in HDPE Outer Layers: Robust and resilient against chemicals and damage.
  • Single wound: For straightforward installation, providing a flat, even surface.
  • CE Marked: Compliant with EN 13967:2012+A1:2017 standards for waterproofing.
  • BS8485:2015 + A1:2019 Compliant: Meets methane gas transmission rate specifications.
  • Meets NHBC Foundation Guidance NF94: Suitable for Type A, B, and C membrane locations.
  • CIRIA C748 Performance Guidance: Adheres to recommended performance standards.
  • BRE BR 211:2023: Fully compliant with current specifications.
  • NHBC Amber 1 & Amber 2 Applications: Approved for various risk applications.
  • Suitable for All Ground Gas Regimes: Effective in any characteristic gas situation (CS).
  • Fully Welded Systems: Compatible with welding for secure, long-lasting installations.
  • Integrated Components and Tapes: Full range of accessories available for complete system integration.

•Material – PE/EVOH membrane & Non-woven polypropylene geotextile fleece

• Colour – Purple/Grey

• Thickness – 1.9mm

• Roll sizes – 1.65m x 30mtr

Downloads

Pre-formed Corners, Top Hats & Ancillaries

Gas Barrier System Solutions

The Rhinoplast gas barrier system solutions service has been established to provide a complete design service to overcome many problems associated with construction on land associated with a range of hazardous gasses. Principal can offer a full technical support to recommend and design products that can simplify, improve, and accelerate installations to meet site specific gas regimes.

We offer a full plot and site-specific schedule service to ensure full site compliance and all components can be either standard issue or uniquely CAD designed with technical supported on-site visits.
